Downlight Fittings For Fibre Optics

UFO 11D Downlight Fitting

An adjustable recessed downlight fitting, secured through the mounting surface with spring clips.
Available in a range of finishes, the eyeball in this fitting can be rotated and tilted to point directly at any objects to be illuminated. The light beam from this fitting is also focusable.
Also suitable for mounting in the base of a display case and illuminating upwards.
316 stainless steel version is suitable for use in wet areas.
TECHNICAL INFORMATION
Lens18mm biconvex clear focusing lens
Focus Range30° - 50°;
Rotation & Tilt360° rotation / 20° tilt
MaterialAluminium, Stainless Steel or Polycarbonate
Available FinishesAluminium: black, white, chrome or natural
Stainless Steel: natural
Polycarbonate: black, white
WeightAluminium: 47.1g
Polycarbonate: 21.9g
Mounting MethodRecessed, secured with springs
Mounting Hole Size40mm
Ferrule SizeM10 or 8mm smooth
Fibre Sizes2mm to 8mm
CONFIGURATIONS Click the option buttons below to create the fitting model number

Model Type

Material

Finish

Ferrule

Model Number:
