UFO CR1 Crystal Fitting
High quality European glass crystal fitting which gives a sparkling light point and a decorative surrounding pattern of light.
Suitable for use with either polymer or glass fibre. Normal fibre sizes used with these fittings are 1.5mm, 1.8mm or 2mm, depending on the brightness required.
As an optional extra, we can supply accessory tubes which allow these fittings to be mounted through single or double skinned ceilings. These are available in 25mm, 80mm or 135mm lengths.
| TECHNICAL INFORMATION | |
|---|---|
| Flange Material | Brass or Polycarbonate |
| Flange Colour | Chrome, Gold, White*, Custom to order |
| Crystal Diameter | 8.2mm (note that due to crystals being handmade diameter can vary slightly) |
| Crystal Drop Length | 13mm (note that due to crystals being handmade length can vary slightly) |
| Recess Depth | 15.5mm |
| Flange Diameter | 15.5mm |
| Ferrule & Fibre Sizes | 1.5mm & 1.8mm fibre - 3.5mm crimp ferrule 2mm fibre - 5mm crimp ferrule |
| Cut Out Sizes (For Crystal Fittings) | Fitting into plasterboard: 10.6mm diameter Fitting into MDF, ply or hardboard - 11.4mm diameter |
| Cut Out Sizes (For Accessory Tubes) | Fitting into plasterboard: 11.8mm diameter Fitting into MDF, ply or hardboard - 12mm diameter |
| CONFIGURATIONS | Click the option buttons below to create the fitting model number |
|---|
Model Type
Material Type
Finish
Fibre Size
Model Number:
Accessory Tubes
Manufactured from translucent plastic, the sleeves allow easy mounting through single or double skinned substrates. Finished with an internal and external ribbed surface to grip the cut out hole and the crystal.
| Product Code | Size |
|---|---|
| ATCR25 | 25mm long |
| ATCR80 | 80mm long |
| ATCR135 | 135mm long |
